Puxing Radio PX-777 VHF 136-174Mhz Transceiver 5W 1200mAh battery Walkie Talkie

Sold 32 only 999999999 item(s) left
$52.50 $99.00 Save $46.50
Sold 32
Material:  PX-777-V
Quantity
Share the love
Free worldwide shipping
Support Returns
made in China
Secure payments
Description

Puxing PX-777 VHF 136-174 Mhz 5W 1200mAh battery Portable Two Ray Radio









Note: if you need the software, please contact us.

Feature

128 Groups of memory channels

50 Groups of CTCSS and 104 Groups of DCS

Wide(25kHz) and Narrow(12.5kHz) available

Come with 1200mAh Li-ion battery

Input Freq. By using keypad

VOX built-in

Scan function

Three color LCD backlight display

Emergency Alarm

Programmable by PC

Bell ring when receiving signal

Priority Scan Function

Adjust power Hi/Lo

Switching between Channel/Freq.

Adjust squelch level(0-9)

Busy channel lockout

Keypad lock


General Specifiction:

Frequency Range: PX-777   VHF:136-174Mhz

Channels: 128

Channel Steps: 5k,10k,6.25k,12.5k,25k

Power Supply: 7.2V 1200mah LI-ion

Operating Temperature: -20°C ~ +60°C

Communication Range: 8 ~20km

Dimension (H x W x D): 100 x 55.5 x 31mm

Weight: 225g





Receiver Specifiction:

Sensitivity < 0.20KV

Selectivity: 65dB

Intermodulation Rejection: 60dB

AF Output: 500mW

Standby Current: 35mA

Transmitter Specifiction:

Power Output: (VHF)5W

Modulation Type: F3E

Spurious Emission < -65dB

Transmit Current: 1300mA/750mA

Max. Deviation: ±5kHz

Modulation Distortion < 5%

Frequency Stability: ±2.5ppm
