The BaoFeng UV-5R is a compact hand held transceiver providing 4 watts
in the frequency range of 136- 174 MHz and 400-480 MHz.
It is a compact, economical HT that includes special VHF receive band from 65 - 108 MHz which includes the regular
FM broadcast band. Dual watch and dual reception is supported.
The transceiver is a micro-miniature multiband FM transceiver with extensive receive frequency coverage, providing
local-area two-way amateur communications along with unmatched monitoring capability.
Functions:1. Frequency Range: 136-174 / 400-520 MHz 2. Dual-Band Display, Dual Freq. Display, Dual-Standby 3. Output Power: 4 /1Watts 4. 128 Channels 50 CTCSS and 104 DCS 5. Built-in VOX Function 6. 1750Hz Brust Tone 7. FM Radio (65.0MHz-108.0MHz) 8. LED Flashlight 9. Large LCD Display 10. High /Low RF Power Switchable 11. 25KHz/12.5KHz Switchable 12. Emergency Alert 13. Low Battery Alert 14. Battery Saver 15. Time-out Timer 16. Keypad Lock 17. Monitor Channel 18. Channel Step: 2.5/5/6.25/10/12.5/25KHz 19. ROGER SET
Specifications :Frequency Range: 65-108MHz (FM Receive only); 136-174 MHz and 400-520 MHz (TX/RX) Channel No.: 128 Frequency Stability: ±2.5ppm Operating Voltage: DC 7.4V Output power: 4W / 1W (Max 5W) Dimension（W x H x D）: 100 x 52 x 32 mm Weight: 250g （including battery, antenna）
Package Content:
1 x BaoFeng UV-5R (VHF136-174MHz / UHF 400-520MHz) Two-Way Radio1x 7.4V 1800mAh Li-ion Battery Pack1x Antenna 136-174/400-479.995Mhz1x Earphone Mic/Headset
1x Belt Clip1x Hand Strap1x ENG Manual1x Adapter1x Desktop Charger (100V-240V)FCC: 2AJGM-UV5R
